Figure CL.02 - Closed Loop SID Pattern : SID diagram

Created:	11/20/2022 6:34:14 AM
Modified:	8/15/2023 12:11:08 PM
Project:
Author:	Kevin Scaggs
Version:	1.0.0
Advanced:
ID:	{D56C1F3C-A157-49b6-A5EF-0E75E4D7C0B6}

This diagram illustrates the relationships between Activity, Goal, and Workflow. The implication is to state the information relationship between a Goal, that defines the purpose of a Closedloop, the underlying Workflows that manage the control path (controlflow) and feedback paths, as well as scenarios where a unitary Actvity acts in standalone in the Closedloop. <br/>
