Figure SI.02-I06c StockLocation and Resources : Object diagram

Created:	5/10/2022 11:24:37 AM
Modified:	5/16/2022 5:44:53 PM
Project:
Author:	Natha Paquette
Version:	1.0.0
Advanced:
ID:	{00D0F3F2-A971-48f8-AE55-DEE3EA190EAF}

When John Smith orders a Rented Livebox, the corresponding Offer and Product are created. Once the Resource is destocked and assigned to John Smith Product, the StockItemStockLevel is debited and the Resource is assigned to John Smith Product
